Single-rotors UAV
Fixed Wing UAV
TCAS, ADSB,
Parachute
We Are Propel Aerial Services
PROPEL AERIAL AIR CRAFTAIR CRAFTS TYPES
- MULTI-ROTOR UAV
- SINGLE-ROTOR UAV
- FIXED WING UAV
Multi-rotor UAV
The Perimeter 8 UAV features an impressive 12 lb. / 5.5 kg payload capacity with 1 hour of endurance and a no-payload endurance of over 5 hours. The Perimeter 8 is just as easy to operate as the Perimeter 4, but has full propeller, motor, and ESC redundancy. This redundancy in addition to electronic fuel injection and a 5 minute battery backup reserve flight time ensures the safety of high-value payloads.
Configuration
- 5 hour endurance in hover
- 12 lb. (5.5 kg) payload capacity
- 15°F to 113°F (-10°C to 45°C) operation
- 25 mph wind gust tolerance
- 55KMflight range
- Fuel injected for high reliability and ease of use.
Single-rotor UAV
The ep b1000 is a single-rotor hybrid-electric UAV designed for ease of deployment, and small form factor. It is ideal for all survey and inspection applications where space, manoeuvrability and deployment speed are critical. The aircraft supports a wide variety of third-party payload and applications
Configurations
| XLRS | Extra long-range surveillance up to 55 km away from the operator. |
| LRS | Long range surveillance up to 35 km away from the operator. |
| MRS | Medium range surveillance up to 10 km away from the operator. |
| MAG | Magnetometer surveys with terrain following and obstacle avoidance. |
| 4 (Base) | Generic surveying and mapping with little or no payload-to-autopilot integration |
Fixed Wing UAV
Serial production small unmanned aerial system for different long-range missions, ISTAR solutions, and SAR applications.
Man-portable (one-box) system ready to be deployed in minutes. The modular flying platform makes the changing of various function modules easy. Payload packages can alternatively include radio relays and electric warfare/countermeasure equipment.
Vertically integrated design and production allow us to manufacture systems to the Client’s needs. This also provides for top-notch maintenance during UAS exploitation and enables modifications as Client’s needs evolve.
Specifications
- Flight time – more than 24 hours
- Operating ceiling – 3000 m
- Speed (min / cruising / max) – 80 / 120 / 160 km/h
- Range in the direct control mode – 240 km
- Range of Full HD real-time video transmission – 120 km
* all parameters are adjustable according to Client’s needs
REVERSE ENGINEERING
Safety upgrades- ADS-B technology to give drone pilots enhanced situational awareness and help them make responsible decisions while flying. This feature gathers flight data sent automatically from nearby aircraft with ADS-B transmitters, analyzing it to detect potential collision risks and alert users well in advance through the DJI mobile app.
SAFETY BEACONS
TCAS
ADSB- TRANSPONDER
PAYLOAD INTEGRATION WITH THIRD PARTY DRONES
Agricultural
Survey and mapping
Thermal and zoom
Multispectral
Single Sensors
GPR- Ground Penetration Radar RADAR
GPS
